Description
Traditionally, PoE switch delivers power and data within the distance of the 100 meter limitation. The GS1350 series fulfills the need to deploy IP camera or power devices using existing Cat 5e cable to distant locations. By enabling extended-range mode, instantly achieve distant deployments up to 250m. Save your money and effort with simply one PoE.
The GS1350 series includes four models with large power budgets of up to 375 W accommodating the requirement for powering up multiple IP cameras. The intuitive LED indicator on the front panel allows inspecting real-time PoE status. In addition, the one-touch "Restore" button on GS1350 Series helps effortless recovery from misconfigurations.
-
New outlook
Coated in titanium gray, the GS1350 excels with an eye-catching identity dedicated for surveillance Switch. -
Easy for long-distance deployment
Traditionally, PoE switch delivers power and data within the distance of the 100 meter limitation. The GS1350 series fulfills the need to deploy IP camera or power devices using existing Cat 5e cable to distant locations. By enabling extended-range mode, instantly achieve distant deployments up to 250m. Save your money and effort with simply one PoE. -
High power budget, intuitive front panel design
The GS1350 series includes four models with large power budgets of up to 375 W accommodating the requirement for powering up multiple IP cameras. The intuitive LED indicator on the front panel allows inspecting real-time PoE status. In addition, the one-touch "Restore" button on GS1350 Series helps effortless recovery from misconfigurations.
Specifications
Summary
- Product Description
- Zyxel GS1350-12HP - switch - 8 ports - smart - rack-mountable
- Device Type
- Switch - 8 ports - smart
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 8 x 10/100/1000 (PoE+) + 2 x 10/100/1000 (uplink) + 2 x Gigabit SFP (uplink)
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 130 W
- Performance
- Switching capacity: 24 Gbps , Forwarding rate: 17.8 Mpps , Packet buffer size: 525 KB
- MAC Address Table Size
- 8K entries
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, RSTP, STP
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI, NTP, ICMP, DHCP, RSTP, RADIUS
- Features
- Flow control, IGMP snooping, Syslog support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Weighted Fair Queuing (WFQ), DHCP snooping, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), DHCP client, Management Information Base (MIB), dual firmware images, Strict Priority Queuing (SPQ), Neighbor Discovery Protocol (NDP), port isolation, Class of Service (CoS), 8KV/15KV ESD Protector, DiffServ Code Point (DSCP) support, IGMP filtering, CPU protection, 4KV Surge protection, Loop Guard, LLDP-MED, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), VLAN trunking
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
- Power
- AC 120/230 V (50/60 Hz)
- Dimensions (WxDxH)
- 26.7 cm x 16.2 cm x 4.4 cm
- Weight
- 1.63 kg
- Localisation
- United Kingdom
Detailed Specification
General
- Device Type
- Switch - 8 ports - smart
- Enclosure Type
- Desktop, rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 8 x 10/100/1000 (PoE+) + 2 x 10/100/1000 (uplink) + 2 x Gigabit SFP (uplink)
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 130 W
- Performance
- Switching capacity: 24 Gbps , Forwarding rate: 17.8 Mpps , Packet buffer size: 525 KB
- MAC Address Table Size
- 8K entries
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, RSTP, STP
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, CLI, NTP, ICMP, DHCP, RSTP, RADIUS
- Encryption Algorithm
- SSL, SHA-2
- Authentication Method
- Secure Shell (SSH), RADIUS
- Features
- Flow control, IGMP snooping, Syslog support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Weighted Fair Queuing (WFQ), DHCP snooping, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), DHCP client, Management Information Base (MIB), dual firmware images, Strict Priority Queuing (SPQ), Neighbor Discovery Protocol (NDP), port isolation, Class of Service (CoS), 8KV/15KV ESD Protector, DiffServ Code Point (DSCP) support, IGMP filtering, CPU protection, 4KV Surge protection, Loop Guard, LLDP-MED, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), VLAN trunking
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Expansion / Connectivity
- Interfaces
- 8 x 1000Base-T RJ-45 PoE+ , 2 x 1000Base-T RJ-45 uplink , 2 x 1000Base-X SFP uplink
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 160.3 Watt
Miscellaneous
- Rack Mounting Kit
- Included
- MTBF
- 1,065,025.45 hours
- Compliant Standards
- FCC, RoHS, BSMI CNS 13438, C-Tick Class A, LVD, BSMI CNS 14336-1, EN 62368-1
- Localisation
- United Kingdom
Dimensions & Weight
- Width
- 26.7 cm
- Depth
- 16.2 cm
- Height
- 4.4 cm
- Weight
- 1.63 kg
Environmental Parameters
- Min Operating Temperature
- -20 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
