Description
The ZyXEL GS1900 range has the features, performance and versatility you'll need to optimize your network, plus the efficiency to bring down your bills. The high-performance and energy-smart managed switch range is designed to cut your bills and protect your investment with intelligent, high-power PoE options, and optimized power consumption. The range includes switches with 8 to 48 ports, High Power PoE models, and SFP uplink options. Advanced traffic management is included as standard alongside all the other features you would expect from a ZyXEL switch, including user-friendly web-based management, IPv6 support and integrated security.
-
Avoid downtime and maximize throughput with Advanced Network Error prevention
Loop protection and storm control keep your network running at top speed while dual image firmware and Dos detection ensure robust, high availability connectivity. -
Quick and easy deployment with web management and set-up wizards
Even complex configurations take no more than a few clicks and a matter of minutes, saving time and resources while accelerating deployment. -
Designed for any location; server room, board room or desk
Silent, fanless operation plus flexible desk, wall or rack mounting options make this the ideal solution for use throughout your organization. -
High-powered, intelligent PoE to protect your investment
With PoE+ the rising power demand of powered devices is met. Additionally each PoE port automatically reserves only the power it needs with programmable feed priority. This ensures the maximum number of devices can be powered, protecting your ROI. -
Gigabit to the desktop
When videos of high resolution and data flow constantly evolve, GbE bandwidth to desktops becomes essential to ensure sufficient bandwidth for all business communications, data delivery and daily operations. -
Reduce your energy bills and carbon footprint
Inactive link detection, cable length detection and EEE compliant traffic detection all minimize power usage by matching power consumption to true demand. -
Future-proof your investment with IPv6 support
Full IPv6 support with features including autoconfiguration, duplicate address prevention, dual-stack and neighbor discovery will ensure your investment is protected. -
Find your perfect solution with flexible chassis options
From 8 ports to 48 ports with gigabit SFP uplink options and Intelligent PoE available on 8, 24 and 48 port models, the GS1900 range will include the perfect switch for your application. -
High level security to safeguard your network
A host of security features including RADIUS and TACACS+ support, SSL, port security, static MAC forwarding and layer 2 MAC filtering, will ensure maximum protection for your network. -
Stream real-time voice and video without a glitch
Extensive QoS and CoS features such as 802.1Q VLAN tagging, Voice VLAN, input priority mapping, 802.1p Class of Service and IP TOS precedence will ensure realtime service for even the most demanding applications.
Specifications
Summary
- Product Description
- Zyxel GS1100 Series GS1100-24E - switch - 24 ports - unmanaged - rack-mountable
- Device Type
- Switch - 24 ports - unmanaged
- Enclosure Type
- Rack-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 24 x 10/100/1000
- Performance
- Switching capacity: 48 Gbps , Forwarding performance: 35.7 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 10KB
- Features
- Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), fanless, Class of Service (CoS), 525KB packet buffer, Energy-Efficient Ethernet (EEE)
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
- Power
- AC 100-240 V (50/60 Hz)
- Dimensions (WxDxH)
- 26.7 cm x 16.2 cm x 4.2 cm
- Weight
- 1.5 kg
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 24 ports - unmanaged
- Enclosure Type
- Desktop, rack-mountable, wall-mountable
- Subtype
- Gigabit Ethernet
- Ports
- 24 x 10/100/1000
- Performance
- Switching capacity: 48 Gbps , Forwarding performance: 35.7 Mpps
- MAC Address Table Size
- 8K entries
- Jumbo Frame Support
- 10KB
- Features
- Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), fanless, Class of Service (CoS), 525KB packet buffer, Energy-Efficient Ethernet (EEE)
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
- Built-in Devices
- Led panel
Expansion / Connectivity
- Interfaces
- 24 x 1000Base-T RJ-45
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 100-240 V (50/60 Hz)
Miscellaneous
- Included Accessories
- Wall mounting kit
- Rack Mounting Kit
- Included
- MTBF
- 366,919 hours
- Compliant Standards
- Plug and Play, BSMI, ICES-003, FCC, RoHS, REACH, LVD, EMC Class A, EAC, RCM
Dimensions & Weight
- Width
- 26.7 cm
- Depth
- 16.2 cm
- Height
- 4.2 cm
- Weight
- 1.5 kg
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 10 - 95% (non-condensing)
