Description
Combining the power of advanced microprocessor, a high-resolution megapixel sensor and Zebra's exclusive PRZM Intelligent Imaging technology, the premium DS8108 delivers the very best in scanning performance to increase transactions and reduce customer wait time in the busy, scan-intensive environments. Innovative features let you go beyond just capturing barcodes.
-
Efficient barcode scanning
The Zebra DS8108-SR barcode scanner utilizes PRZM Intelligent Imaging technology to handle various barcode types including QR codes and Data Matrix, ensuring smooth operation in any setting. -
Robust construction
Built to withstand the rigors of everyday use, this scanner is compliant with IP42 standards, offering protection against dust and splashes, suitable for diverse work environments. -
Wide operational range
This device functions effectively across a temperature range of 0 °C to 50 °C and can operate within a humidity spectrum of 5% to 95%, enabling it to perform in various conditions. -
User-friendly notifications
The DS8108-SR features both an LED indicator and beeper for operational confirmations, allowing users to know when a scan has been successfully completed. -
Durable design
With a drop specification of 1.8 m to concrete, this handheld barcode scanner is designed to endure shocks and vibrations, ensuring longevity and reliability in demanding environments.
Specifications
Summary
- Product Description
- Zebra DS8108-SR - Standard Range (SR) - barcode scanner
- Type
- Barcode scanner - handheld - USB - decoded
- Colour
- Twilight black
- Minimum Bar Width
- 3 mil
- Scan Element Type
- 2D imager
- Sensor Resolution
- 1280 x 960
- Connectivity Technology
- Wired
- Dimensions (WxDxH)
- 6.6 cm x 10.7 cm x 16.8 cm
- Weight
- 154 g
- Manufacturer Warranty
- 5-year warranty
Detailed Specification
General
- Type
- Barcode scanner - handheld
- Colour
- Twilight black
Barcode
- Interface Type
- USB
- Minimum Bar Width
- 3 mil
- Scan Element Type
- 2D imager
- Sensor Resolution
- 1280 x 960
- Light Source Wave Length
- 617 nm
- Scan Mode
- Single-pass
- Skew (Degrees)
- 60
- Pitch (Degrees)
- 60
- Print Contrast Signal (PCS)
- 16%
- Decode Capability
- Code 39, QR code, Code 128, Data Matrix
- TTL Decoding
- Decoded
- Connectivity Technology
- Wired
- OK Notification
- Beeper, LED indicator
- Features
- PRZM Intelligent Imaging technology
Processor
- Clock Speed
- 800 MHz
Expansion / Connectivity
- Interfaces
- 1 x USB
Miscellaneous
- Included Accessories
- Cradle
- Cables Included
- 1 x USB cable
- Compliant Standards
- EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, RoHS, FIPS 140-2, UL 60950-1, CAN/CSA C22.2 No. 60950-1-07, IP42, EN 50581, IEC 62471, EN 55032 Class B, ICES-003 issue 6 Class B, EN60950-1 (2nd Edition) + A11 + A1 + A12 + A2:2013, EN60950-1 (2nd Edition) + A1 + A2
Power
- Electric Current Required
- 450 mA (operating)
Dimensions & Weight
- Width
- 6.6 cm
- Depth
- 10.7 cm
- Height
- 16.8 cm
- Weight
- 154 g
Manufacturer Warranty
- Service & Support
- Limited warranty - 5 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Drop Specification
- 1.8 m to concrete
