Description
WiFi 7 Mesh speed
9.3 Gbps Tri-Band WiFi 7 – 5765 Mbps (6 GHz) + 2882 Mbps (5 GHz) + 688 Mbps (2.4 GHz)
2.5 Gbps Wired Connections
4× 2.5 Gbps ports ensure max flexibility and boosted throughput
Wireless and Wired Combined Backhaul
Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency
Multi-Link Operation (MLO)
Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability
320 MHz Channels
Double the bandwidth and enables many more simultaneous transmissions at the fastest possible speeds
Works on the 6 GHz Band
Minimizes congestion with greenfield spectrum, delivering robust high-speed connections
TP-Link HomeShield
Provides comprehensive network protection, robust parental controls, and real-time IoT security
Universal Compatibility
Backward compatible with all WiFi generations and works with any internet service provider (ISP) and modem
Compatible with New iPhone
The new iPhone 16 and 16 Pro now support the latest WiFi 7 standard, while TP-Link WiFi 7 Mesh delivers the speed and performance of this next-gen WiFi technology
-
Wi-Fi 7, Wi-Fi like never before
Wi-Fi 7 has arrived with jam-dropping performance - offering accelerated throughput, lower latency, stronger anti-jamming and higher efficiency. Join the league of pros and experiance the sheer performance of the next generation Wi-Fi. -
2.5 Gbps wired backhaul
Most of the home is covered by 2.5 Gbps high-speed connections. The edge of the house also remained at around 2 Gbps. This builds the true whole home Multi-Gigabit mesh Wi-Fi. -
Wireless backhaul
The Deco BE65 remains the same as with a wired backhaul. But due to the walls and ceiling between the two floors, the center of the other Deco BE65 receives at least 1.5 Gbps speeds. -
Ultra-fast 2.5 Gbps wired performance
4x 2.5 Gbps ports maximize home Internet speeds with up to 2.5x the wired speed of a typical Gigabit Ethernet port. The additional USB 3.0 port makes Deco BE65 an ideal solution for future-proofing your home network. Connect your favorite wired devices to Deco BE65 and get impressed. -
The ultimate backhaul
Through self-developed technology, Deco BE65 can connect a wireless and wired backhaul with each unit simultaneously. What's more, with the advanced Wi-Fi 7 MLO technology, the system's wireless and wired combined backhaul aggregation flow rate is increased. This way, it greatly improves overall throughput and reduces latency, delivering broader coverage with more stable and reliable connections. -
Smart security for smart living
HomeShield provides a series of built-in services that protect all your devices comprehensively with various features for when you're at home or on the go. With HomeShield, safer Internet experiences bring more happiness to your smart living. -
Seamless AI-Driven mesh
Deco Mesh forms a unified network with a single network name. With built-in AI-Roaming technology, it creates the ideal Wi-Fi solution with its advanced algorithms and self-learning. Walk through your home and enjoy seamless streaming at a fast possible speeds.
Specifications
Summary
- Product Description
- TP-Link Deco BE65 V1 - Wi-Fi system - Wi-Fi 7 - desktop
- Device Type
- Wi-Fi system - mesh
- Enclosure Type
- Desktop
- Wi-Fi System Components
- 3 routers
- Wi-Fi System Coverage
- Up to 7,800 sq.ft
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11be (Wi-Fi 7)
- Frequency Band
- 2.4 GHz / 5 GHz / 6 GHz
- Data Transfer Rate
- 9.3 Gbps
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps , Maximum data rate (5 GHz): 2880 Mbps , Maximum data rate (6 GHz): 5760 Mbps , Channel bandwidth: up to 320 MHz
- Capacity
- Connected devices: up to 200 , Streams: 6
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP, DDNS, IPv4, IPv6, OpenVPN
- Routing Protocol
- IGMP, static IP routing
- Intelligent Assistant
- Google Assistant, Alexa
- Remote Management Protocol
- IPv4, IPv6
- Features
- Auto-sensing per device, IGMP snooping, IPS, parental control, Access Point operational mode, DDos attack prevention, QoS, DHCP server, port forwarding, reset button, SPIF, DHCP client, FOTA, IGMP proxy, router mode, Backhaul Technology, 2x2 MU-MIMO technology, VLAN Tagging, schedule reboot, OpenVPN server, IPTV support, WPS button, BSS Coloring, Guest Network, Address Reservation, Real-Time IoT Protection, Malicious Site Blocker, Home Network Scanner, AI-Driven Mesh, MLO
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, UPnP, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax, IEEE 802.11be, Wi-Fi CERTIFIED 7
- Power
- AC 120/230 V
- Dimensions (WxDxH)
- 10.75 cm x 10.75 cm x 17.6 cm
- Manufacturer Warranty
- 3-year warranty
Detailed Specification
General
- Device Type
- Wi-Fi system - mesh - 4-port switch (integrated)
- Wi-Fi System Components
- 3 routers
- Wi-Fi System Coverage
- Up to 7,800 sq.ft
- Enclosure Type
- Desktop
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11be (Wi-Fi 7)
- Frequency Band
- 2.4 GHz / 5 GHz / 6 GHz
- Data Transfer Rate
- 9.3 Gbps
- Performance
- Maximum data rate (2.4 GHz): 574 Mbps , Maximum data rate (5 GHz): 2880 Mbps , Maximum data rate (6 GHz): 5760 Mbps , Channel bandwidth: up to 320 MHz
- Capacity
- Connected devices: up to 200 , Streams: 6
- Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP, DDNS, IPv4, IPv6, OpenVPN
- Routing Protocol
- IGMP, static IP routing
- Remote Management Protocol
- IPv4, IPv6
- Encryption Algorithm
- WPA3-Personal, WPA2-Personal, WPA-Personal
- Wi-Fi Rating
- BE9300
- Mesh Networking
- Yes
- Features
- Auto-sensing per device, IGMP snooping, IPS, parental control, Access Point operational mode, DDos attack prevention, QoS, DHCP server, port forwarding, reset button, SPIF, DHCP client, FOTA, IGMP proxy, router mode, Backhaul Technology, 2x2 MU-MIMO technology, VLAN Tagging, schedule reboot, OpenVPN server, IPTV support, WPS button, BSS Coloring, Guest Network, Address Reservation, Real-Time IoT Protection, Malicious Site Blocker, Home Network Scanner, AI-Driven Mesh, MLO
- Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, UPnP, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax, IEEE 802.11be, Wi-Fi CERTIFIED 7, FCC, RoHS
Line Properties
- Line Coding Format
- 4096 QAM, OFDMA
Internet of Things (IoT)
- Internet of Things (IoT) Compatible
- Yes
- Intelligent Assistant
- Google Assistant, Alexa
Expansion / Connectivity
- Interfaces
- WAN / LAN: 4 x 2.5GBase-T - RJ-45 , USB 3.0: 1 x 9 pin USB Type A
Aerial
- Aerial
- Internal
- Antenna Qty
- 4
Power
- Power Device
- External power adapter
- Installed Qty
- 3
- Voltage Required
- AC 120/230 V
Miscellaneous
- Cables Included
- 1 x network cable
Dimensions & Weight
- Width
- 10.75 cm
- Depth
- 10.75 cm
- Height
- 17.6 cm
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% RH
