Description
TL-SF1005LP is a 5 10/100 Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
-
Power Over Ethernet
Four of the 5 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). -
Overload arrangement
TL-SF1005LP has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 41 W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port. -
Intelligent power management
Priority (port-1=port-2=port-3>port-4): this function will help to ensure the normal operation of the system; it means Port 4 will be cut off when all total PoE PDs power consumption exceeds 41 W. For example. If port 1, 2 and 4 are consuming 10 W respectively, and an additional PoE device with 15.4 W is inserted to port 3, the system will cut off the power of port 4 to compensate for the overload. -
Ease of use
TL-SF1005LP is easy to install and use. It requires no configuration and installation. With desktop and wall mountable design, outstanding performance and quality, the TP-Link's TL-SF1005LP 5-Port 10/100 Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your network.
Specifications
Summary
- Product Description
- TP-Link TL-SF1005LP - V1 - switch - 5 ports - unmanaged
- Device Type
- Switch - 5 ports - unmanaged
- Subtype
- Fast Ethernet
- Ports
- 5 x 10/100 (4 PoE)
- Power Over Ethernet (PoE)
- PoE
- PoE Budget
- 41 W
- Performance
- Packet forwarding rate: 0.744 Mpps , Switching capacity: 1 Gbps
- MAC Address Table Size
- 2K entries
- Jumbo Frame Support
- 2KB
- Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, fanless, metal housing, priority mode, extend mode, security slot (Kensington security lock compatible), Intelligent Power Management
- Compliant Standards
- IEEE 802.3af, IEEE 802.3x
- Dimensions (WxDxH)
- 10 cm x 9.8 cm x 2.5 cm
Detailed Specification
General
- Device Type
- Switch - 5 ports - unmanaged
- Enclosure Type
- Desktop, wall-mountable
- Subtype
- Fast Ethernet
- Ports
- 5 x 10/100 (4 PoE)
- Power Over Ethernet (PoE)
- PoE
- PoE Budget
- 41 W
- Performance
- Packet forwarding rate: 0.744 Mpps , Switching capacity: 1 Gbps
- MAC Address Table Size
- 2K entries
- Jumbo Frame Support
- 2KB
- Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, fanless, metal housing, priority mode, extend mode, security slot (Kensington security lock compatible), Intelligent Power Management
- Compliant Standards
- IEEE 802.3af, IEEE 802.3x
Expansion / Connectivity
- Interfaces
- 5 x 100Base-TX RJ-45 4 ports (PoE) - 15.4 W
Power
- Power Device
- External power adapter
- Power Provided
- 53.5 V - 0.81 A
- Power Consumption Operational
- 47 Watt
Miscellaneous
- Compliant Standards
- Plug and Play, FCC, RoHS
Dimensions & Weight
- Width
- 10 cm
- Depth
- 9.8 cm
- Height
- 2.5 cm
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 90% (non-condensing)
