Description
The PEXSAT32 2-Port PCI Express SATA 6 Gbps (SATA 3.0) Controller Card offers simple connectivity between a host computer and SATA 3.0 devices - a cost-effective solution for connecting high-speed storage, such as High RPM Hard Drives and Solid State Drives (SSD), which in turn allows for easier data backups and archiving.
With full support for SATA 3.0 hard drives and data transfer speeds of up to 6 Gbps, the adapter card features a native PCI Express single chipset that provides enhanced compatibility, reliability and performance for external SATA 600 MB/s storage needs.
The controller card is backward compatible with SATA 2.0 devices, providing the versatility to use older storage, and features support for RAID 0 and 1 modes as well as port multiplier capability with command-based and FIS-based switching for connecting multiple external hard drives to a host PC through a single SATA connection.
A dual profile solution, the SATA 3.0 controller card includes a low profile/half-height bracket for installation in slimline or small form factor computer cases.
-
Versatile Hardware RAID Configurations
This RAID controller supports different hardware RAID configurations to meet your specific application: • RAID 0 (striped) - Splits your data evenly across both drives to increase read/write performance, while also increasing the size of your volume storage capacity to the combined total of both drives. • RAID 1 (mirrored) - Exactly copies your data on both drives to provide data redundancy, so your data will be safely backed-up should one of the drives fail. • SPAN (big) - Combines both drives into a single array to increase the size of your volume storage capacity to the combined total of both drives. • JBOD (Just a bunch of disks) - Exposes both drives as individual devices to be treated independently. -
ASM1062R to Deliver 2-Port SATA 6Gbps Performance
Featuring the ASM1062R controller, this SATA card enables the connection of two high-performance SATA 6Gbps drives with a combined total throughput of up to 8Gbps. The SATA drives are connected via two individual SATA ports located on the card (SATA cables sold separately). -
Wide Compatibility
The controller card is widely supported across all popular operating system platforms including Windows (7, 8, 10, 11), macOS (10.10 and above) and Linux (2.6.32 and above). Plus, with support for PCIe 2.0 and SATA III Specifications this card ensures backward compatibility with previous generations (SATA I/II, PCIe 1) at lower performance. For managing and configuring RAID functionality, the card supports OS booting on Windows & Linux for BIOS level RAID setup & configuration, and includes an application on Windows for OS level RAID setup, configuration & monitoring. On macOS only software RAID is supported using RAID Assistant. -
Hassle-Free Installation
The SATA controller card features plug-and-play installation and can be installed in a full-profile or low-profile computer systems with the full-profile bracket preinstalled, and an interchangeable low-profile (half-height) bracket included. 2P6GR-PCIE-SATA-CARD is backed by a StarTech.com lifetime warranty and free lifetime 24/5 North American based, multi-lingual support.
Specifications
Summary
- Product Description
- StarTech.com SATA PCIe Card, 2 Port PCIe SATA Expansion card, 6Gbps SATA Card, Full/Low Profile, PCI Express to SATA Adapter, ASM1062R SATA RAID Controller Card - PCIe to SATA Converter - storage controller - SATA 6Gb/s - PCIe 2.0 x2
- Device Type
- Storage controller - plug-in card - low profile
- Bus Type
- PCIe 2.0 x2
- Colour
- Red
- Interface
- SATA 6Gb/s
- Data Transfer Rate
- 6 Gbit/s
- Supported Devices
- Hard drive, solid state drive
- RAID Level
- RAID 0, RAID 1, JBOD
- System Requirements
- Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Apple MacOS X 10.10 or later, Linux 2.6.32 or later
- Dimensions (WxDxH)
- 2.2 cm x 6.9 cm x 12.1 cm
- Weight
- 35 g
- Manufacturer Warranty
- Limited lifetime warranty
Detailed Specification
General
- Device Type
- Storage controller - plug-in card - low profile
- Host Bus
- PCIe 2.0 x2
- Colour
- Red
Storage Controller
- Interface
- SATA 6Gb/s
- Data Transfer Rate
- 6 Gbit/s
- Supported Devices
- Hard drive, solid state drive
- RAID Level
- RAID 0, RAID 1, JBOD
- Processor
- ASMedia ASM1062R
Expansion / Connectivity
- Interfaces
- 2 x SATA 6Gb/s - SATA (internal)
Miscellaneous
- Included Accessories
- Low-profile bracket
- Features
- Support port multiplier, S.M.A.R.T. support, TRIM support, 4Kn drive compatible, bootable, ATAPI support
- Compliant Standards
- Plug and Play, RoHS
Software / System Requirements
- OS Required
- Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Apple MacOS X 10.10 or later, Linux 2.6.32 or later
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Dimensions & Weight
- Width
- 2.2 cm
- Depth
- 6.9 cm
- Height
- 12.1 cm
- Weight
- 35 g
Dimensions & Weight (Shipping)
- Shipping Width
- 14.2 cm
- Shipping Depth
- 17 cm
- Shipping Height
- 3 cm
- Shipping Weight
- 126 g
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 85 °C
- Humidity Range Operating
- 20 - 80%
