Description
Easily connect and hot swap a SSD or HDD from a 3.5in bay. Now it's easy to increase the storage capabilities of your server or PC while protecting data integrity. This one-bay mobile rack backplane lets you install and easily remove a 2.5in SAS or SATA HDD or SDD in a 3.5in external expansion bay on your desktop PC or server. It's ideal for system integrators and administrators looking for flexible management of data storage.
The backplane provides an easy, convenient way to install and swap drives between desktops or servers. It supports both SAS and SATA 2.5in drives ranging from 5 to 15mm in height. To maximize the performance of your hard drives, the mobile rack supports SAS II and SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller.
Many fast-paced work environments require drives to be removed regularly. This convenient backplane lets you hot swap between systems quickly, without shutting down. The included drive tray is interchangeable, working with both the single-bay backplane and the 4-bay backplane (SATSASBP425) so you can hot swap between systems for easy file access.
Engineered with high quality metal, the robust metal housing delivers reliable performance. The venting helps to ensure proper air flow to assist with heat dissipation.
The Non-Scratch SATA (NSS) connector provides a high 50,000+ insertion rating, your assurance of long-lasting performance of both the drives and the bay.
Specifications
Summary
- Product Description
- StarTech.com Mobile Rack Backplane for 2.5" SATA/SAS Drive - Supports 5mm-15 mm SSDs/HDDs - Hot Swap Vented Metal Enclosure (SATSASBP125) - storage drive cage
- Device Type
- Storage drive cage
- Colour
- Black, silver
- Expansion Bays
- 1 x hot-swap - 2.5"
- Compatible Bay
- 1 3.5"
- Hard Drive Form Factor Compatibility
- 2.5"
- Supported Interface
- SATA-600 / SAS 2.0
- Drive Connector
- 22 pin Serial ATA
- Bay Connector
- 22 pin Serial ATA
- Features
- Data indicator, power indicator
- Product Material
- Aluminium, steel
- Dimensions (WxDxH)
- 10.1 cm x 14.1 cm x 2.5 cm
- Weight
- 435 g
- Manufacturer Warranty
- 2-year warranty
- Designed For
- P/N: SATSASBP425
Detailed Specification
General
- Device Type
- Storage drive cage
- Hard Drive Form Factor Compatibility
- 2.5"
- Hard Drive Maximum Height
- 15 mm
- Product Material
- Aluminium, steel
- Colour
- Black, silver
- Supported Interface
- SATA-600 / SAS 2.0
- Features
- Data indicator, power indicator
Storage Controller
- Processor
- No CPU
Expansion / Connectivity
- Bays
- 1 x hot-swap - 2.5"
- Interfaces
- 4 x SATA 6Gb/s / SAS 6Gb/s - SATA combo
- Connections
- 1 - 22 pin Serial ATA
- Compatible Bay
- 1 x internal 3.5"
Miscellaneous
- Included Accessories
- Keys
- Cables Included
- 1 x Serial ATA cable
- Features
- Key lock, 2.5" internal drive bay, LED indicator, tested with up to 2TB 7200 RPM 2.5" hard drives
- Mounting Kit
- Included
- Compliant Standards
- FCC, RoHS
Manufacturer Warranty
- Service & Support
- Limited warranty - 2 years
Dimensions & Weight
- Width
- 10.1 cm
- Depth
- 14.1 cm
- Height
- 2.5 cm
- Weight
- 435 g
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 55 °C
Compatibility Information
- Designed For
- P/N: SATSASBP425
