Description
The XS728T 10-Gigabit Ethernet Smart Managed Switch brings the second generation of 10-Gigabit Copper switching to SMBs. The XS728T is a powerful Smart Managed Switch that includes 24 ports of 10-Gigabit connectivity (24 copper with 4 dedicated 10-Gigabit SFP+ Fiber ports). NETGEAR's 10-Gigabit Smart Managed Switches are purposely designed as a cost-effective way to provide 10G connections to 10G-capable servers and NAS (Network Attached Storage) systems. The XS728T provides comprehensive L2+/Layer 3 Lite features (including IPV6 management) allowing SMB customers to deploy virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, which require higher reliability, speed, and performance. It can be used at the "center of a small business network" or as an aggregation/access switch in a larger organization. The XS728T is ideal for is ideal for expanding network capacity, removing performance bottlenecks and/or support of premise expansion needs.
-
Robust security
With support for RADIUS and TACACS+ authentication methods, alongside TLS 1.0 and TLS 1.2 encryption algorithms, this switch ensures secure network access and data transmission. -
Efficient performance
Featuring a switching fabric bandwidth of 560 Gbps and a 3 MB packet buffer, the NETGEAR Smart XS728T facilitates efficient data processing and high-speed connectivity. -
Advanced networking
Equipped with Layer 3 Lite advanced switching, IPv4 and IPv6 support, and comprehensive routing protocols including IGMP, MLD, and static routing, this switch is designed for sophisticated network architectures. -
Enhanced manageability
Manageable via HTTP, HTTPS, SNMP, and RMON, this device offers versatile remote management options, making network administration more convenient and efficient. -
Extensive connectivity
With 24 10GBase-T ports and 4 10 Gigabit SFP+ ports, alongside a dedicated USB 2.0 management port, the switch provides ample connectivity options for diverse networking requirements.
Specifications
Summary
- Product Description
- NETGEAR Smart XS728T - switch - 28 ports - smart - rack-mountable
- Device Type
- Switch - 28 ports - L3 Lite - smart
- Enclosure Type
- Rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x 10GBase-T + 4 x 10 Gigabit SFP+
- Performance
- Switching fabric bandwidth: 560 Gbps
- Capacity
- ACL: 164 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 64 , IPv6 routes: 64 , Priority queues per port: 8 , ARP entries: 1024 , DHCP snooping entries: 1000
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, MLDv2, MLD
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
- Features
- Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, IPv4 support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, static routing, CoS, 802.1x authentication, ToS, DSCP support, 4 fans, 3MB packet buffer, cable test, administrator's password, layer 2+ switching
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
- Power
- AC 120/230 V
- Dimensions (WxDxH)
- 44 cm x 31 cm x 4.3 cm
- Weight
- 5.04 kg
- Localisation
- Latin America, North America, Europe
- Manufacturer Warranty
- NETGEAR lifetime warranty
Detailed Specification
General
- Device Type
- Switch - 28 ports - L3 Lite - smart
- Enclosure Type
- Desktop, rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x 10GBase-T + 4 x 10 Gigabit SFP+
- Performance
- Switching fabric bandwidth: 560 Gbps
- Capacity
- ACL: 164 , Virtual interfaces (VLANs): 512 , IGMP groups: 512 , IPv4 routes: 64 , IPv6 routes: 64 , Priority queues per port: 8 , ARP entries: 1024 , DHCP snooping entries: 1000
- MAC Address Table Size
- 16K entries
- Jumbo Frame Support
- 10KB
- Routing Protocol
- IGMPv2, IGMP, IGMPv3, MLDv2, MLD
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS
- Encryption Algorithm
- TLS 1.0, TLS 1.2
- Authentication Method
- RADIUS, TACACS+
- Features
- Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, WRR queuing, store and forward, Broadcast Storm Control, IPv6 support, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MLD snooping, IPv4 support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, static routing, CoS, 802.1x authentication, ToS, DSCP support, 4 fans, 3MB packet buffer, cable test, administrator's password, layer 2+ switching
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3az
- Processor
- : 800 MHz
- RAM
- 512 MB
- Flash Memory
- 256 MB
- Status Indicators
- Port transmission speed, power, link/activity, fan
Expansion / Connectivity
- Interfaces
- 24 x 10GBase-T RJ-45 , 4 x 10GBase-X SFP+ , 1 x USB 2.0 management
Power
- Power Device
- Internal power supply
- Voltage Required
- AC 120/230 V
- Power Consumption Operational
- 173.3 Watt
Miscellaneous
- Included Accessories
- Rubber feet
- Rack Mounting Kit
- Included
- MTBF
- 514,977 hours
- Compliant Standards
- cUL, EN 60950, IEC950, UL 1950, EN55024, CSA 22.2 No. 950, EN55022 Class A, CISPR 22, CCC, FCC Part 15 A, C-Tick Class A, SCC, VCCI Class A, TLS v1.2, TLS v1.0
- Localisation
- Latin America, North America, Europe
Software / System Requirements
- Software Included
- Drivers & Utilities
Dimensions & Weight
- Width
- 44 cm
- Depth
- 31 cm
- Height
- 4.3 cm
- Weight
- 5.04 kg
Manufacturer Warranty
- Service & Support
- NETGEAR lifetime warranty
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 50 °C
- Humidity Range Operating
- 90% (non-condensing)
- Min Storage Temperature
- -20 °C
- Max Storage Temperature
- 70 °C
