Description
This multifunctional device offers all the benefits of a professional document management solution for workgroups and small offices. Advanced functionality, easy to operate, and a range of paper-handling options, all in a well-designed compact package. Cost-efficient and eco-friendly offices will appreciate KYOCERA's unique ECOSYS technology which increases operating life, reduces environmental impact, cuts printing costs and ensures reliability.
-
Efficient connectivity
With interfaces for Gigabit Ethernet, USB 2.0, and USB 2.0 host, this device ensures seamless integration into any office network, facilitating easy sharing and communication. -
Advanced security
Equipped with IPsec and SSL protocols, it offers robust security features to protect sensitive information and ensure peace of mind. -
Versatile media handling
Supports a wide range of media sizes from A6 to A3 and weights up to 256 g/m2, making it ideal for diverse printing needs, from standard documents to large-format prints. -
High-quality copying
Features like automatic duplexing, multiple copying features including ID Card Copy and electronic sorting, alongside a maximum copying resolution of 600 x 600 DPI, ensure crisp, clear copies every time. -
Eco-friendly design
ENERGY STAR certified, this device not only meets high environmental standards but also ensures efficient energy use, contributing to lower operating costs.
Specifications
Summary
- Product Description
- Kyocera ECOSYS M4125idn - multifunction printer - B/W
- Device Type
- Multifunction printer
- Printing Technology
- Laser (monochrome)
- Max Copying Speed
- Up to 25 ppm
- Max Copying Resolution
- Up to 600 x 600 dpi
- Max Printing Speed
- Up to 25 ppm
- Max Printing Resolution
- Up to 1200 x 1200 dpi
- Scanning
- 600 x 600 dpi
- Display
- 4.3"
- Original Size
- 98 x 148 mm (min) - A3/Ledger (297 x 432 mm) (max)
- Original Type
- Sheets
- Document Feeder Capacity
- 50 sheets
- Media Size
- 98 x 148 mm (min) - A3 (297 x 420 mm), ANSI B (Ledger) (279 x 432 mm) (max)
- Media Type
- Plain paper
- Standard Media Capacity
- 600 sheets
- Max Media Capacity
- 1600 sheets
- Output Trays Capacity
- 300 sheets
- Automatic Duplexing
- Yes (copying) Yes (printing) Yes (scanning)
- Connection Availability
- Yes
- Interface
- USB 2.0, Gigabit LAN, USB 2.0 host
- Office Machine Features
- Scan to e-mail, scan to folder, HyPAS (Hybrid Platform for Advanced Solutions), Private print, Kyocera ECOSYS Technology, scan to FTP, scan to SMB, print from e-mail, IPP printing, scan to USB host
- Power
- AC 230 V (50/60Hz)
- Dimensions (WxDxH)
- 59 cm x 59 cm x 68.8 cm
- Weight
- 49 kg
- Environmental Standards
- ENERGY STAR Qualified
Detailed Specification
General
- Device Type
- Multifunction printer
- Printing Technology
- Laser - monochrome
- Display Diagonal Size
- 4.3"
- Display Colour Support
- Colour
- Display Features
- Touch screen
- Connection Availability
- Yes
- Interface
- USB 2.0, Gigabit LAN, USB 2.0 host
- Office Machine Features
- Scan to e-mail, scan to folder, HyPAS (Hybrid Platform for Advanced Solutions), Private print, Kyocera ECOSYS Technology, scan to FTP, scan to SMB, print from e-mail, IPP printing, scan to USB host
Memory
- Standard Memory
- 1 GB
- Max Supported Memory
- 3 GB
- Supported Flash Memory
- SD Memory Card
Copying
- Max Copying Speed
- Up to 25 ppm
- Max Copying Resolution
- Up to 600 x 600 dpi
- Max Document Enlargement
- 400%
- Max Document Reduction
- 25%
- Maximum Copies
- 999
- Exposure Control
- Automatic, manual
- Exposure Modes
- Text, photo, text and photo, map
- Automatic Duplexing
- Yes
- Copying Features
- 2 on 1, 4 on 1, ID Card Copy, reverse copy, blank page skipping, electronic sorting, Scan-once-copy-many, programme mode
Printing
- Max Printing Resolution
- Up to 1200 x 1200 dpi
- Max Printing Speed
- Up to 25 ppm
- Printer Drivers / Emulations
- PCL 5e, PCL 6, PostScript 3, KPDL3, PCL 6 (XL), PDF, XPS, PRESCRIBE IIe
- Automatic Duplexing
- Yes
- First Print Out Time B/W
- 5.8 sec
Scanning
- Automatic Duplexing
- Yes
- Optical Resolution
- 600 x 600 dpi
Document & Media Handling
- Min Original Size
- 98 x 148 mm
- Max Original Size
- A3/Ledger (297 x 432 mm)
- Original Type
- Sheets
- Document Feeder Capacity
- 50 sheets
- Min Media Size
- 98 x 148 mm
- Max Media Size
- A3/Ledger
- Min Media Weight
- 45 g/m²
- Max Media Weight
- 256 g/m²
- Supported Media Type
- Plain paper
- Supported Media Sizes
- ANSI A (Letter) (216 x 279 mm), Legal (216 x 356 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A3 (297 x 420 mm), A6 (105 x 148 mm), ANSI B (Ledger) (279 x 432 mm), Folio (216 x 330 mm)
- Standard Media Capacity
- 600 sheets
- Max Media Capacity
- 1600 sheets
- Output Trays Capacity
- 300 sheets
- Document & Media Handling Details
- Input tray - 500 sheets - A3/Ledger (297 x 432 mm) weight: 60 g/m² - 163 g/m² , Input tray - 100 sheets size: 98 x 148 mm - A3/Ledger (297 x 432 mm) weight: 45 g/m² - 256 g/m² , ADF - 50 sheets size: 140 x 182 mm - A3/Ledger (297 x 432 mm) weight: 45 g/m² - 160 g/m² , Output tray - 250 sheets , Job separator tray - 50 sheets
- Speed Details
- Printing: up to 25 ppm (A4) - B/W , Printing: up to 12 ppm (A3) - B/W , Copying: up to 25 ppm (A4) - B/W , Copying: up to 12 ppm (A3) - B/W , Scanning: up to 50 ipm (A4) - B/W (300 dpi) , Scanning: up to 20 ipm (A4) - colour (300 dpi) , Copying: up to 22 ppm (A4) - B/W duplex , Printing: up to 22 ppm (A4) - B/W duplex
Connections
- Interfaces
- 1 x USB 2.0 - 4 pin USB Type B , 2 x USB 2.0 host - 4 pin USB Type A , 1 x Gigabit LAN - RJ-45
- Security Protocols & Features
- SSL, IPsec
- Operating System Support
- UNIX, Linux, Apple Mac OS X 10.5 or later, MS Windows
Power
- Voltage Required
- AC 230 V (50/60Hz)
- Power Consumption Operational
- 410 Watt
- Power Consumption Standby
- 65 Watt
- Power Consumption Sleep
- 0.5 Watt
Miscellaneous
- Warm-Up Time
- 20 sec
- First Copy Out Time B/W
- 7 sec
- Compliant Standards
- TUV GS, ISO 9001, ISO 14001
Environmental Standards
- ENERGY STAR Certified
- Yes
Dimensions & Weight
- Width
- 59 cm
- Depth
- 59 cm
- Height
- 68.8 cm
- Weight
- 49 kg
Environmental Parameters
- Sound Emission
- 34 dBA (idle) / 49 dBA (operating)
