Description
Do you need a dense platform with built-in security and flexibility that addresses key applications such as virtualization and software-defined storage? The HPE ProLiant DL325 Gen10 offers an exceptional balance of processor, memory and I/O for virtualization and data intensive workloads.
-
Innovative design
HPE ProLiant DL325 Gen10 has a dense chassis that accommodates several drive options. You can adapt and grow to changing business needs. -
Security innovations
Secure recovery allows server firmware to roll back to the last known good state or factory settings after detection of compromised server. Additional security options are available with TPM to avoid unauthorized access to the server and store artifacts used to authenticate the server platforms, while the intrusion detection kit logs and alerts when the server hood is removed for further protection.
Specifications
Summary
- Product Description
- HPE ProLiant DL325 Gen10 Performance - rack-mountable - EPYC 7302P 3 GHz - 16 GB - no HDD
- Type
- Server - rack-mountable
- Height (Rack Units)
- 1U
- Server Scalability
- 1-way
- Processor
- 1 x AMD EPYC 7302P / 3 GHz (3.3 GHz) (16-core)
- Processor Socket
- Socket SP3
- Cache Memory
- 128 MB L3 Cache
- Cache Per Processor
- 128 MB
- RAM
- 16 GB (installed) / 1 TB (max) - DDR4 SDRAM
- Storage Controller
- RAID (SATA 6Gb/s / SAS 12Gb/s) (HPE Smart Array P408i-a)
- Server Storage Bays
- Hot-swap 2.5"
- Hard Drive
- No HDD
- Optical Storage
- No optical drive
- Card Reader
- Yes
- Video Memory
- 16 MB
- Networking
- GigE
- Power
- AC 120/230 V (50/60 Hz)
- Power Redundancy
- Optional
- Dimensions (WxDxH)
- 43.46 cm x 61.49 cm x 4.29 cm
- Weight
- 10.7 kg
- Environmental Standards
- ENERGY STAR Qualified
- Manufacturer Warranty
- Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Detailed Specification
General
- Type
- Server
- Product Form Factor
- Rack-mountable - 1U
- Built-in Devices
- Led panel, battery
- Server Scalability
- 1-way
- Hot-Swap Bays Qty
- 8
Processor / Chipset
- CPU
- AMD EPYC 7302P
- Clock Speed
- 3 GHz
- Max Turbo Speed
- 3.3 GHz
- Number of Cores
- 16-core
- CPU Qty
- 1
- Max CPU Qty
- 1
- CPU Upgradability
- Upgradable
- CPU Socket
- Socket SP3
Cache Memory
- Installed Size
- L3 Cache - 128 MB
- Cache Per Processor
- 128 MB
RAM
- Installed Size
- 16 GB / 1 TB (max)
- Technology
- DDR4 SDRAM
- Effective Memory Speed
- 2933 MHz
- Rated Memory Speed
- 2933 MHz
- Form Factor
- DIMM 288-pin
- Slots
- 16 (Total) / 15 (empty)
- Features
- Registered, HPE SmartMemory
- Configuration Features
- 1 x 16 GB
- RAM Supported
- PC4-20800 - 2 TB Load-Reduced , PC4-20800 - 1 TB registered
Hard Drive
- Type
- No HDD
Storage Controller
- Type
- 1 x RAID
- Controller Interface Type
- SATA 6Gb/s / SAS 12Gb/s
- Storage Controller Name
- HPE Smart Array P408i-a
- Channel Qty
- 8
- RAID Level
- RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
- Buffer Size
- 2 GB
Optical Storage
- Type
- No optical drive
Card Reader
- Type
- Card reader
- Supported Flash Memory Cards
- microSD
Monitor
- Monitor Type
- None.
Graphics Controller
- Video Memory
- 16 MB
- Video Interfaces
- VGA
Networking
- Ethernet Ports
- 4 x Gigabit Ethernet
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol
- SNMP 3, IPMI 2.0, SMASH CLP
- Remote Management Controller
- Integrated Lights-Out 5
- Features
- Wake on LAN (WoL), PXE support
Expansion / Connectivity
- Bays
- 1 (total) / 1 (free) x external , 8 (total) / 8 (free) x hot-swap 2.5" SFF
- Slots
- 1 (total) / 1 (free) x FlexibleLOM - three-quarter-length, full-height (low-profile) , 1 (total) / 1 (free) x PCIe 3.0 x16 - full-height , 1 (total) / 1 (free) x PCIe 3.0 x8 (low-profile) , 1 (total) / 1 (free) x microSD Card (internal)
- Interfaces
- 1 x HPE iLO - Type A (1 in front) , 5 x USB 3.0 (1 front, 2 rear, 2 internal) , 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) , 1 x HPE iLO - RJ-45 (1 rear) , 1 x VGA (1 rear)
Miscellaneous
- Included Accessories
- HPE Easy Install Rails, 5 x standard hot plug fans
- Compliant Standards
- AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
- Device Type
- Power supply - hot-plug
- Power Redundancy
- Optional
- Power Redundancy Scheme
- 1+1 (with optional power supply)
- Installed Qty
- 1
- Max Supported Qty
- 2
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Provided
- 800 Watt
- 80 PLUS Certification
- 80 PLUS Platinum
Operating System / Software
- OS Certified
- CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi)
Sustainability Information
- ENERGY STAR Certified
- Yes
- ENERGY STAR Version
- 2.1
Manufacturer Warranty
- Service & Support
- Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
- Width
- 43.46 cm
- Depth
- 61.49 cm
- Height
- 4.29 cm
- Weight
- 10.7 kg
Environmental Parameters
- Min Operating Temperature
- 10 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 8 - 90% (non-condensing)
- Sound Emission
- 37 dBA
