Description
Do you need a dense platform with built-in security and flexibility that addresses key applications such as virtualization and software-defined storage? The HPE ProLiant DL325 Gen10 offers an exceptional balance of processor, memory and I/O for virtualization and data intensive workloads.
-
Delivering 2P Performance at 1P Economics
HPE ProLiant DL325 Gen10 server supports industry standard technology utilizing the AMD EPYC 7000 series processor family with up to 64 cores, 12Gb SAS and HPE SmartMemory up to 2933 MT/s DDR4 memory.HPE ProLiant DL325 Gen10 server has a dense chassis that accommodates up to 10 SFF, up to 4 LFF, or up to 10 NVMe drive options as well as up to 3 PCIe 3.0 slots.The embedded SATA HPE Smart Array S100i Controller is standard while the redesigned HPE Smart Array Essentials and Performance Controllers allow you the flexibility to choose the 12 Gbps controller to optimize your environment.Options for HPE FlexibleLOM or PCIe standup adapters offer a choice of networking bandwidth (1GbE to 4x10GbE) and fabric enabling you to scale to the changing needs of your business. -
Automation
HPE iLO 5 monitors servers for ongoing management, service alerting, reporting and remote management to resolve issues quickly and keep your business running from anywhere in the world.HPE OneView is an automation engine that transforms compute, storage, and networking into software-defined infrastructure to automate tasks and speed business process implementations.HPE InfoSight provides built-in AI predicts problems before they happen, proactively resolves issues, and continually learns as it analyzes data-making every system smarter and more reliable.HPE iLO RESTful API feature provides iLO RESTful API extensions to Redfish allowing you to take full advantage of the wide range of value-added API features, and integrate easily with leading orchestration tools. -
Security
Silicon Root of Trust is an immutable fingerprint in the iLO silicon. The silicon root of trust validates the lowest level firmware to BIOS and software to ensure a known good state.Tied into the silicon root of trust is the AMD Secure Processor, a dedicated security processor embedded in the AMD EPYC system on a chip (SoC). The security processor manages secure boot, memory encryption and secure virtualization.Run Time Firmware Validation validates the iLO and UEFI/BIOS firmware at runtime. Notification and automated recovery is executed on detection of compromised firmware.If system corruption has been detected Server System Restore will automatically alert iLO Amplifier Pack to initiate and manage the system recovery process, avoiding lasting damage to your business by quickly restoring firmware to the factory settings or the last known authenticated safe setting. -
Optimization
HPE Right Mix Advisor provides data-driven guidance drives the ideal hybrid cloud mix for workloads allowing for intelligent planning speeding migrations from months to weeks and controlling the cost of migration.HPE GreenLake Flex Capacity provides pay-per-use IT consumption on-premises, with real-time tracking and metering of resource usage, so you have the capacity you need to deploy quickly, pay for the exact resources you consume, and avoid overprovisioning.HPE Foundation Care helps when there is a hardware or software problem offering several response levels dependent on IT and business requirements.HPE Proactive Care is an integrated set of hardware and software support including an enhanced call experience with start to finish case management helping resolve incidents quickly and keeping IT reliable and stable.HPE Financial Services helps you transform to a digital business with financing option and trade-in opportunities that align to your business goals.
Specifications
Summary
- Product Description
- HPE ProLiant DL325 Gen10 Performance - rack-mountable - EPYC 7302P 3 GHz - 16 GB - no HDD
- Type
- Server - rack-mountable
- Height (Rack Units)
- 1U
- Server Scalability
- 1-way
- Processor
- 1 x AMD EPYC 7302P / 3 GHz (, up to 3.3 GHz, (16-core)
- Processor Socket
- Socket SP3
- Cache Memory
- 128 MB L3 Cache
- Cache Per Processor
- 128 MB
- RAM
- 16 GB (installed) / 1 TB (max) - DDR4 SDRAM
- Storage Controller
- RAID (SATA 6Gb/s / SAS 12Gb/s) (HPE Smart Array P408i-a)
- Server Storage Bays
- Hot-swap 2.5"
- Hard Drive
- No HDD
- Optical Storage
- No optical drive
- Card Reader
- Yes
- Video Memory
- 16 MB
- Networking
- 1GbE
- Power
- AC 120/230 V (50/60 Hz)
- Power Redundancy
- Optional
- Dimensions (WxDxH)
- 43.46 cm x 61.49 cm x 4.29 cm
- Weight
- 10.7 kg
- Environmental Standards
- ENERGY STAR Qualified
- Manufacturer Warranty
- Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Detailed Specification
General
- Type
- Server
- Product Form Factor
- Rack-mountable - 1U
- Built-in Devices
- Led panel, battery
- Server Scalability
- 1-way
- Hot-Swap Bays Qty
- 8
Processor / Chipset
- CPU
- AMD EPYC 7302P
- Clock Speed
- 3 GHz
- Max Turbo Speed
- 3.3 GHz
- Number of Cores
- 16-core
- CPU Qty
- 1
- Max CPU Qty
- 1
- CPU Upgradability
- Upgradable
- CPU Socket
- Socket SP3
Cache Memory
- Installed Size
- L3 Cache - 128 MB
- Cache Per Processor
- 128 MB
RAM
- Installed Size
- 16 GB (installed) / 1 TB (max)
- Technology
- DDR4 SDRAM
- Effective Memory Speed
- 2933 MHz
- Rated Memory Speed
- 2933 MHz
- Form Factor
- DIMM 288-pin
- Slots
- 16 (Total) / 15 (empty)
- Features
- Registered, HPE SmartMemory
- Configuration Features
- 1 x 16 GB
- RAM Supported
- PC4-20800 - 2 TB Load-Reduced , PC4-20800 - 1 TB registered
Hard Drive
- Type
- No HDD
Storage Controller
- Type
- 1 x RAID
- Controller Interface Type
- SATA 6Gb/s / SAS 12Gb/s
- Storage Controller Name
- HPE Smart Array P408i-a
- Channel Qty
- 8
- RAID Level
- RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
- Buffer Size
- 2 GB
Optical Storage
- Type
- No optical drive
Card Reader
- Type
- Card reader
- Supported Flash Memory Cards
- microSD
Monitor
- Monitor Type
- None.
Graphics Controller
- Video Memory
- 16 MB
- Video Interfaces
- VGA
Networking
- Ethernet Ports
- 4 x Gigabit Ethernet
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol
- SNMP 3, IPMI 2.0, SMASH CLP
- Remote Management Controller
- Integrated Lights-Out 5
- Features
- Wake on LAN (WoL), PXE support
Expansion / Connectivity
- Bays
- 1 (total) / 1 (free) x external , 8 (total) / 8 (free) x hot-swap 2.5" SFF
- Slots
- 1 (total) / 1 (free) x FlexibleLOM - three-quarter-length, full-height (low-profile) , 1 (total) / 1 (free) x PCIe 3.0 x16 - full-height , 1 (total) / 1 (free) x PCIe 3.0 x8 (low-profile) , 1 (total) / 1 (free) x microSD Card (internal)
- Interfaces
- 1 x HPE iLO - Type A (1 in front) , 5 x USB 3.0 (1 front, 2 rear, 2 internal) , 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) , 1 x HPE iLO - RJ-45 (1 rear) , 1 x VGA (1 rear)
Miscellaneous
- Included Accessories
- HPE Easy Install Rails, 5 x standard hot plug fans
- Compliant Standards
- AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
- Device Type
- Power supply - hot-plug
- Power Redundancy
- Optional
- Power Redundancy Scheme
- 1+1 (with optional power supply)
- Installed Qty
- 1
- Max Supported Qty
- 2
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Provided
- 800 Watt
- 80 PLUS Certification
- 80 PLUS Platinum
Operating System / Software
- OS Certified
- CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi)
Sustainability Information
- ENERGY STAR Certified
- Yes
- ENERGY STAR Version
- 2.1
Manufacturer Warranty
- Service & Support
- Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
- Width
- 43.46 cm
- Depth
- 61.49 cm
- Height
- 4.29 cm
- Weight
- 10.7 kg
Environmental Parameters
- Min Operating Temperature
- 10 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 8 - 90% (non-condensing)
- Sound Emission
- 37 dBA
