Keeping the same 450W cooling capacity using only 2 slots, the WINDFORCE 3X 450W cooling system is equipped with two 8mm and four 6mm cooper heat-pipes, inclined fans, and GIGABYTE "Triangle Cool" technology. This not only provides an effective heat dissipation capacity but GPU Boost 2.0 technology also enables higher performance due to a lower temperature.

In the Kepler architecture, support up to four displays on a single card. Satisfy your multi-screen setup, high definition and extreme gaming experience.

• WINDFORCE 3X 450W Cooling system
• 8+2 phase VRM power design
• Powered by NVIDIA GeForce GTX 780 Ti GPU
• Integrated with industry's best 3GB GDDR5 memory 384-bit memory interface
• Features Dual-link DVI-I/ DVI-D / HDMI / DisplayPort
• BASE:1020 MHz / BOOST:1085 MHz
• System power supply requirement: 600W

Brand-new instinctive user interface, easier to monitoring and adjusting all important settings. Users can set up MONITORING, GPU CLOCK, MEMORY CLOCK,FAN, OSD, ONLINE SUPPORT and update driver, BIOS directly.

Compared to the 6-phase reference design, the GV-N780OC-3GD provides a more stable voltage output while having the MOSFET working at lower temperatures. Moreover, temperature protection and load balance to each MOSFET can effectively extends the graphics card life.

Specifications

• Chipset GeForce GTX 780 Ti
• Memory Clock 7000 MHz
• Process Technology 28 nm
• Memory Size 3072 MB
• Memory Bus 384 bit
• Core Clock Base / Boost clock:1020 / 1085 MHz
• Card Bus PCI-E 3.0
• Memory Type GDDR5
• DirectX 11.2
• OpenGL 4.4
• PCB Form ATX
• Digital max resolution 4096 X 2160(via a single HDMI connector and not supported with two DVI connectors)
• Analog max resolution 2048 x 1536
• Multi-view 4
• I/O DVI-I*1
• DVI-D*1
• DisplayPort*1
• HDMI*1
• Card size L=292mm, W=129mm, H=43mm
• Power requirement 600W (with two 8-pin external power connectors)
