Intel NUC Kit Rock Canyon, UCFF, Core i3 5010U / 2.1 GHz, DDR3L, M.2, Intel HD 5500

Review this product
Quicklinx: B32NWS00 Mfr#: BOXNUC5i3RYK
  • Core i3
  • Bluetooth 4.0
  • IEEE 802.11n
Discontinued

Description

The 4-inch square Intel NUC NUC5i3RYK takes the powerful capabilities of a desktop system and packages it into a computer that fits in the palm of your hand. This fully scalable system comes with 5th generation Intel Core i3 processor and integrated Intel HD Graphics with 4K display support. Whether you want a digital jukebox, home hub, or light gaming PC, the Intel NUC NUC5i3RYK gives you the power to play, create, entertain, and inspire. The system is designed to hold a lightning fast and compact M. 2 SSD so you can quickly stream music or movie files, and also features consumer infrared and a Mini HDMI video interface. With Intel WiDi you can connect your monitor without any additional cables and Bluetooth lets you place wireless speakers where you want - all the features you want in a space-saving, clutter-free design. A replaceable lid gives you plenty of options to create the NUC you want - with amazing style and features. There's also a high-speed USB 3.0 charging port that lets you easily charge your tablet or smartphone quickly. And for peace of mind you'll get embedded security that helps keep threats out, user identities and credentials safe, and your data protected.

  • Superior processing and graphics

    Visibly smart graphics using the advanced processor deliver amazing performance and visually stunning graphics.
  • Stunningly small form factor

    The compact form factor unlocks a world of potential design applications, from digital signage and kiosks to portable innovations.
  • Advanced technology

    The NUC features two sockets for expandability of memory, two mini-card connectors for flexible support of wireless and hard drive configurations, BIOS vault technology, fast boot and the Visual BIOS. The NUC also supports The Anti-Theft technology, providing hardware intelligence, designed to protect your device and its data, if its lost or stolen.

Specifications

Summary

Product Description
Intel Next Unit of Computing Kit NUC5i3RYK - mini PC - Core i3 5010U 2.1 GHz - 0 GB - no HDD
Type
PC barebone - mini PC - voltage monitoring, temperature sensor, Intel Rapid Start Technology, MIMO technology, Intel Rapid Storage Technology, 1 USB 3.0 charging port, fan speed controller, built-in infrared sensor, Intel Ready Mode Technology
Processor
1 x Intel Core i3 (5th Gen) 5010U / 2.1 GHz (Dual-Core)
Processor Main Features
Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Wireless Display, Intel 64 Technology, Intel AES New Instructions
Cache Memory
3 MB L3 Cache
Cache Per Processor
3 MB
RAM
0 GB (installed) / 16 GB (max) - DDR3L SDRAM
Hard Drive
No HDD
Optical Storage
No optical drive
Graphics Controller
Intel HD Graphics 5500
Audio Output
7.1 channel surround - integrated
Networking
1GbE, 802.11a, 802.11b/g/n, Bluetooth 4.0, Wi-Fi 5
OS Provided
No operating system
Dimensions (WxDxH)
11.5 cm x 11.1 cm x 3.45 cm
Manufacturer Warranty
Limited warranty - 3 years


Detailed Specification

General

Type
PC barebone
Product Form Factor
Mini PC
Built-in Devices
Infrared receiver

Processor / Chipset

CPU
Intel Core i3 (5th Gen) 5010U
Clock Speed
2.1 GHz
Number of Cores
Dual-Core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Not upgradable
Processor Main Features
Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Wireless Display, Intel 64 Technology, Intel AES New Instructions

Cache Memory

Installed Size
L3 Cache - 3 MB
Cache Per Processor
3 MB

RAM

Installed Size
0 GB / 16 GB (max)
Technology
DDR3L SDRAM
Form Factor
SO-DIMM 204-pin
Slots
2 (Total) / 2 (empty)
Features
Dual channel memory architecture

Hard Drive

Type
No HDD

Storage Controller

Type
Integrated

Optical Storage

Type
No optical drive

Monitor

Monitor Type
None.

Graphics Controller

Type
Integrated
Graphics Processor
Intel HD Graphics 5500
Video Interfaces
HDMI, DisplayPort

Audio Output

Type
Integrated
Sound Output Mode
7.1 channel surround
Compliant Standards
High Definition Audio

Networking

Type
Integrated
Wireless LAN Supported
Yes
Wireless NIC
Intel Dual Band Wireless-AC 7265
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac
Features
ACPI support, Intel Wireless Display (WiDi)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac

Expansion / Connectivity

Slots
2 (total) / 2 (free) x SO-DIMM 204-pin , 1 (total) / 1 (free) x M.2 Card
Interfaces
4 x USB 3.0 (2 front, 2 rear) , 1 x Mini-HDMI , 1 x Mini DisplayPort , 1 x headphones/microphone , 1 x LAN (Gigabit Ethernet) - RJ-45 , 2 x USB 2.0 (2 internal) , 2 x SATA-600 (2 internal)

Miscellaneous

Features
Voltage monitoring, temperature sensor, Intel Rapid Start Technology, MIMO technology, Intel Rapid Storage Technology, 1 USB 3.0 charging port, fan speed controller, built-in infrared sensor, Intel Ready Mode Technology
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
EN55022, ICES-003, EN55024, CISPR 22, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, FCC CFR47 Part 15 B, VCCI V-3, VCCI V-4, KN22, KN24, China RoHS, CNS 13438, RoHS 2011/65/EU, WEEE 2002/96/EC, CAN/CSA-C22.2 No. 60950-1

Power

Device Type
Power adapter
Power Provided
65 Watt

Operating System / Software

OS Provided
No operating system

Manufacturer Warranty

Service & Support
Limited warranty - 3 years

Dimensions & Weight

Width
11.5 cm
Depth
11.1 cm
Height
3.45 cm

Environmental Parameters

Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
