Description
GIGABYTE introduces WINDFORCE, the latest cooling technology that differentiates the brand's graphics cards from the rest. GIGABYTE understands that a fan is crucial to the graphics card, so only the fan with the most efficiency is selected for WINDFORCE.
The airflow is spilled through the triangle design at the fan edge, and is guided smoothly through the fan by special 3D stripe curve design. At the same time, it effectively enhanced the cooling capacity while reducing air turbulence.
Equipped with pure copper heat pipe direct touch (HDT) technology, delivering superior cooling capacity and heat transfer efficiency at an extremely low noise level.
GIGABYTE Flex display technology(patent-pending) can automatically detect any connected monitors and achieve multi-display gaming up to 4 monitors at the same time by using various output groups. Users could enjoy the best gaming experience in ultra HD resolution with extended flexibility in arranging monitor configurations and making future system upgrade extremely easy.
-
WINDFORCE 2X cooling system
GIGABYTE introduces WINDFORCE, the latest cooling technology that differentiates the brand's graphics cards from the rest. GIGABYTE understands that a fan is crucial to the graphics card, so only the fan with the most efficiency is selected for WINDFORCE. -
Unique blade fan design
The airflow is spilled through the triangle design at the fan edge, and is guided smoothly through the fan by special 3D stripe curve design. At the same time, it effectively enhanced the cooling capacity while reducing air turbulence. -
Heat pipe direct touch
Equipped with pure copper heat pipe direct touch (HDT) technology, delivering superior cooling capacity and heat transfer efficiency at an extremely low noise level. -
Flex Display technology
GIGABYTE Flex display technology(patent-pending) can automatically detect any connected monitors and achieve multi-display gaming up to 4 monitors at the same time by using various output groups. Users could enjoy the best gaming experience in ultra HD resolution with extended flexibility in arranging monitor configurations and making future system upgrade extremely easy. -
Lower GPU temperature
Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU and memory temperature by doubling the copper inner layer of PCB. -
Better overclocking capability
Ultra Durable VGA board reduces voltage ripples in normal and transient state, thus effectively lowers noises and ensures higher overclocking capability. -
Decrease power switching loss
Ultra Durable VGA board allows more bandwidth for electron passage and reduces circuit impedance. The less circuit impedance, the more stable flow of current and can effectively improve power efficiency. -
OC GURU ll
Intuitive user interface helps you easily modify important settings and directly update driver and BIOS. Clock speeds, voltage, fan performance, and OSD setting can be monitored and tuned in real-time according to your own preference.
Specifications
Summary
- Product Description
- Gigabyte GV-N960OC-4GD (rev. 1.0) - graphics card - GF GTX 960 - 4 GB
- Device Type
- Graphics card
- Bus Type
- PCI Express 3.0 x16
- Graphics Engine
- NVIDIA GeForce GTX 960
- Memory
- 4 GB GDDR5
- Core Clock
- 1216 MHz
- Boost Clock
- 1279 MHz
- Effective Memory Clock
- 7.01 GHz
- Memory Interface
- 128-bit
- Max Resolution
- 4096 x 2160
- Max Monitors Supported
- 4
- Interfaces
- DVI-I (dual link) , DisplayPort , HDMI , DVI-D (dual link)
- API Supported
- OpenGL 4.4, DirectX 12
- Dimensions (WxDxH)
- 4.2 cm x 18.1 cm x 13.6 cm
Detailed Specification
General
- Device Type
- Graphics card
- Bus Type
- PCI Express 3.0 x16
- Graphics Engine
- NVIDIA GeForce GTX 960
- Core Clock
- 1216 MHz
- Boost Clock
- 1279 MHz
- Process Technology
- 28 nm
- Max Resolution
- 4096 x 2160
- Max Monitors Supported
- 4
- Interfaces
- DVI-I (dual link) , DisplayPort , HDMI , DVI-D (dual link)
- API Supported
- OpenGL 4.4, DirectX 12
- Features
- Ultra Durable VGA, Nvidia PhysX-Ready, Nvidia 3D Vision technology, GIGABYTE WindForce 2x, Dual Fan Design, Nvidia SLI ready, NVIDIA Adaptive Vertical Sync, NVIDIA GPU Boost, OC Guru II, Heat Pipe Direct Touch technology
Memory
- Size
- 4 GB
- Technology
- GDDR5 SDRAM
- Effective Clock Speed
- 7.01 GHz
- Bus Width
- 128-bit
System Requirements
- Required Power Supply
- 400 W
- Additional Requirements
- 6 pin PCI Express power connector
Miscellaneous
- Software Included
- OC Guru ll
- Width
- 4.2 cm
- Depth
- 18.1 cm
- Height
- 13.6 cm
